Pressure Transmitter
PT600R-2110-I2-AMP3J1
Order ID no. 100003587
In Stock
Price Group
J1
List Price
€154.70
Item Total
€154.70
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
home
Turck-Shop
Sensors
Pressure Sensors
PT600R-2110-I2-AMP3J1
Technical Data
Downloads
Electrical output
Current output (2-wire)
Ambient temperature max. (°C)
100
Ambient temperature min. (°C)
-40
Approvals
cULus
Electrical connection
Connector
Connector type
AMP JPT
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Process connection
R 1/4″ male thread EN 10226
Media temperature max. (°C)
125
Media temperature min. (°C)
-40
Pressure range
0...600 bar
Operating voltage
DC
Output function
Analog output current
Pressure type
Relative pressure
Protection class
IP67
Key Features
Electrical output
Current output (2-wire)
Process connection
R 1/4″ male thread EN 10226
