Inductive Sensor With Increased Temperature Range
BI2-EM12WDTC-Y1X
Order ID no. 4012051
In Stock
Price Group
E1
List Price
€ 109,45
Item Total
€ 109,45
Quantity
−
+
add_shopping_cart
Add to Cart
home
Turck-Shop
Sensors
Inductive Sensors
BI2-EM12WDTC-Y1X
Technical Data
Downloads
Ambient temperature max. (°C)
100
Ambient temperature min. (°C)
-40
Approvals
, , , , , , ,
Connector type
Removable cage clamp terminals
Design
Threaded barrel
Electrical connection
Terminal chamber
Gehäusedurchmesser (mm)
⌀ 12 mm
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Mounting conditions
Flush
Operating voltage
DC
Output function
NAMUR
Protection class
IP68, IP69K
Quality active face
LCP
Rated switching distance (mm)
2
Special features
Pressure resistant, Wash down
Switching frequency (kHz)
5
Key Features
Electrical connection
Terminal chamber
Mounting conditions
Flush
Output function
NAMUR
Rated switching distance (mm)
2
