BI1.5-EH04-0.3-M12-SIU-H1141 | TURCK - Your Global Automation Partner

Inductive Sensor With Analog Output

BI1.5-EH04-0.3-M12-SIU-H1141

Order ID no. 1533001

homeHome
Loading...

Ambient temperature max. (°C): 70
Ambient temperature min. (°C): -25
Cable length (m): 0.3
Connector type: M12 x 1
Design: Smooth barrel
Electrical connection: Connector
Gehäusedurchmesser (mm): ⌀ 4 mm
Housing material: Stainless steel
Housing quality: 1.4427 SO
Measuring range (mm): 0.1
Mounting conditions: Flush
Operating voltage: DC
Output function: Analog output
Protection class: IP67
Quality active face: PA12-GF30

Key Features

homeTurck-Shop
Sensors
Inductive Sensors
BI1.5-EH04-0.3-M12-SIU-H1141

Electrical connection: Connector
Mounting conditions: Flush
Output function: Analog output

In Stock
Price Group	E1
List Price	€ 208,35

Item Total€ 208,35

Quantity
