REI-E-111TA0C-2B360-C | TURCK - Your Global Automation Partner
Incremental Encoder
REI-E-111TA0C-2B360-C
Order ID no. 100011964
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101545869
Gross weight
247
Height
90
Length
100
Net weight
247
Dimension unit
MMT
Weight unit
GRM
Volume
0.009
Volume unit
HLT
Width
100
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-20
Electrical connection
Cable
Design
Solid shaft
Encoder line
Efficiency-Line
Technology
Optical
Housing material
Aluminium
Output function
Push-Pull/HTL
Output type
Incremental
Measuring principle
Optical
Protection class
IP64
Flange diameter (mm)
40
Flange type
Synchro/clamping flange
Protection class shaft
IP64
Resolution incremental (ppr)
360
Shaft diameter D (mm)
6.35 mm
Shaft Type
Solid shaft
home
Turck-Shop
Sensors
Encoders
REI-E-111TA0C-2B360-C
Key Features
Output type
Incremental
Flange diameter (mm)
40
Shaft diameter D (mm)
6.35 mm
Shaft Type
Solid shaft
In Stock
Price Group
G1
List Price
€168.15
Item Total
€168.15
Quantity
−
+
