PC001V-203-2UPN8X-H1141 | TURCK - Your Global Automation Partner

Pressure Sensor

PC001V-203-2UPN8X-H1141

Order ID no. 6833738

homeHome
Loading...

Ambient temperature max. (°C): 80
Ambient temperature min. (°C): -40
Communication protocol: IO-Link
Connector type: M12 x 1
Design: Without display
Electrical output: 2 x switching output
Electrical connection: Connector
Housing material: Stainless steel
Housing quality: 1.4305 (AISI 303)/PBT-GF15
Material pressure transducer: Ceramic Al₂O₃
Media temperature max. (°C): 85
Media temperature min. (°C): -40
Operating voltage: DC
Output function: PNP/NPN
Pressure range: -1...1 bar
Pressure type: Relative pressure
Process connection: 1/4″ NPT-18 male thread
Protection class: IP67, IP69K
Switching element function: NO/NC

homeTurck-Shop
Others
PC001V-203-2UPN8X-H1141

In Stock
Price Group	G1
List Price	€359.75

Item Total€359.75

Quantity

Contact Support
