- Base unit
- PCE
- EAN/UPC code
- 4047101240436
- Electrical output
- Voltage output (3-wire), 1 × switching output
- Gross weight
- 325
- Height
- 45
- Length
- 150
- Net weight
- 325
- Dimension unit
- MMT
- Weight unit
- GRM
- Volume
- 742.5
- Volume unit
- CMQ
- Width
- 110
- Ambient temperature max. (°C)
- 80
- Ambient temperature min. (°C)
- -40
- Approvals
- cULus
- Communication protocol
- IO-Link
- Electrical connection
- Connector
- Connector type
- M12 x 1
- Design
- With display
- Display
- 4-digit 7-segment display, rotatable by 180°, with switch-off function
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4305 (AISI 303)
- Material pressure transducer
- Ceramic Al₂O₃
- Process connection
- 1/4″ NPT-18 male thread
- Media temperature max. (°C)
- 85
- Media temperature min. (°C)
- -40
- Pressure range
- -1...25 bar
- Operating voltage
- DC
- Output function
- PNP/NPN
- Pressure type
- Relative pressure
- Protection class
- IP67, IP69K
- Switching element function
- NO/NC
