Inductive Sensor

BI2U-MT12E-AD4X-0.3-RS4.23/XOR

Order ID no. 4405048

Special features: uprox+, Factor 1, Resistant to magnetic fields, PTFE-coated
Ambient temperature max. (°C): 70
Ambient temperature min. (°C): 0
Cable color: Orange
Cable length (m): 0.3
Electrical connection: Cable with connector
Connector type: M12 x 1
Design: Threaded barrel
Gehäusedurchmesser (mm): ⌀ 12 mm
Housing material: Metal
Housing quality: CuZn
Housing surface: PTFE-coated
Mounting conditions: Flush
Operating voltage: DC
Output function: 2-wire
Protection class: IP68
Quality active face: LCP
Rated switching distance (mm): 2
Switching element function: NO contact
Switching frequency (kHz): 0.01
