RS-07H6E-7A12B-C 1M | TURCK - Your Global Automation Partner
Absolute Rotary Encoder - Single-Turn
RS-07H6E-7A12B-C 1M
Order ID no. 1544045
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
Special features
Compact
EAN/UPC code
4047101253405
Gross weight
245
Height
90
Length
110
Net weight
245
Dimension unit
MMT
Weight unit
GRM
Volume
891
Volume unit
CMQ
Width
90
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-40
Electrical connection
Cable
Design
Hollow shaft
Encoder line
Industrial-Line
Technology
Magnetic
Housing material
Die-cast zinc
Output function
Analog output
Output type
Absolute singleturn
Measuring principle
Magnetic
Flange diameter (mm)
36
Flange type
Flange with stator coupling
Protection class shaft
IP69K
Shaft diameter D (mm)
6 mm
Shaft Type
Blind hole shaft
In Stock
Price Group
F3
List Price
€514.40
Item Total
€514.40
Quantity
−
+
