TP-504A-TRI1.5-H1141-L100/S3645 | TURCK - Your Global Automation Partner
Temperature Detection
TP-504A-TRI1.5-H1141-L100/S3645
Order ID no. 100048143
home
Home
Loading...
Technical Data
Detection type
medium contact
Design
Temperature probe
Immersion depth L (mm)
100
Process connection
Tri-Clamp 1 1/2″
Electrical output
Resistance
Protection class
IP67
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
120
Approvals
cULus
Measuring range
-50…120 °C
Key Features
Electrical output
Resistance
Process connection
Tri-Clamp 1 1/2″
Measuring range
-50…120 °C
In Stock
Price Group
D2
List Price
€139.45
