PT0.2V-1043-U1-WM0.5 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT0.2V-1043-U1-WM0.5
Order ID no. 100002609
home
Home
Loading...
Technical Data
Design
Without display
Process connection
G 1/2” male thread (front sealing)
Electrical output
Voltage output (3-wire)
Protection class
IP65
Electrical connection
Stranded wires
Connector type
Open end
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Ambient temperature min. (°C)
-30
Ambient temperature max. (°C)
85
Approvals
cULus
Output function
Analog output voltage
Media temperature min. (°C)
-40
Media temperature max. (°C)
125
Pressure type
Relative pressure
Pressure transducer material
Ceramic Al₂O₃
Operating voltage
DC
Pressure range
-0.2…0.2 bar
Key Features
Electrical output
Voltage output (3-wire)
Process connection
G 1/2” male thread (front sealing)
Pressure range
-0.2…0.2 bar
In Stock
Price Group
J1
List Price
€141.25
