Flow Monitoring
FCS-G1/2A4-AP8X-H1141/L080
Order ID no. 6870008| In Stock | |
| Price Group | D2 |
| List Price | €592.50 |
Item Total€592.50
Quantity
- Detection type
- Calorimetric
- Design
- Immersion
- Process connection
- G 1/2''
- Protection class
- IP67
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Stainless steel
- Housing quality
- 1.4571 (AISI 316Ti)
- Ambient temperature min. (°C)
- -20
- Ambient temperature max. (°C)
- 80
- Approvals
- cULus
- Output function
- PNP
- Medium
- liquids
- Switching element function
- NO contact
- Media temperature min. (°C)
- -20
- Media temperature max. (°C)
- 80
- Mounting conditions
- Immersion sensor
- Operating voltage
- DC
Key Features
- Process connection
- G 1/2''
- Output function
- PNP
