FS101-300L-30-AR32-B3151 | TURCK - Your Global Automation Partner
Flow Sensor
FS101-300L-30-AR32-B3151
Order ID no. 100030879
home
Home
Loading...
Technical Data
Switching element function
NO/NC programmable
Output function
Relay output
Electrical connection
Connector
Connector type
1/2-20 UNF male (on device)
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/Grilamid TR90 UV
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
80
Protection class
IP64, IP65
Design
With display (integrated probe)
Mounting conditions
Immersion sensor
Immersion depth L (mm)
16.9
Process connection
G 1/2″ male thread
Electrical output
1 × switching output
Medium
liquids
Media temperature min. (°C)
-25
Media temperature max. (°C)
85
Approvals
CE, cULus
Key Features
Immersion depth L (mm)
16.9
Process connection
G 1/2″ male thread
Output function
Relay output
In Stock
Price Group
D2
List Price
€455.30
