Absolute Rotary Encoder - Multiturn
REM-104HA1T-3C13S12M-H1181
Order ID no. 100011399| In Stock | |
| Price Group | F3 |
| List Price | €693.30 |
Item Total€693.30
Quantity
- Communication protocol
- SSi
- Protection class
- IP67
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Die-cast zinc
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 85
- Measuring principle
- Optical
- Output type
- Absolute multiturn
- Flange type
- Flange with mounting element
- Shaft Type
- Blind hole shaft
- Flange diameter (mm)
- 58
- Shaft diameter D (mm)
- 9.525
Key Features
- Output type
- Absolute multiturn
- Flange diameter (mm)
- 58
- Shaft diameter D (mm)
- 9.525
- Shaft Type
- Blind hole shaft
