Field-Wireable Connector
BKV8140-0/9
Order ID no. 6914538| In Stock | |
| Price Group | K3 |
| List Price | €18.40 |
Item Total€18.40
Quantity
- Application
- Data
- Network protocol
- PROFIBUS-PA, FOUNDATION fieldbus
- Connector A
- Female, M12 × 1, Straight, A-coded
- Number of Pins
- 4
- Connection mode
- Screw/clamp connection
- Screw-in thread
- PG9
- Voltage (V)
- 250
- Coupling nut/screw material A
- Stainless Steel
- Connection technology signal
- M12
Key Features
- Connection mode
- Screw/clamp connection
- Connector A
- Female, M12 × 1, Straight, A-coded
- Number of Pins
- 4
- Application
- Data
