Industrial Ethernet Cable
RSS-FSSD-841-0.5M
Order ID no. 6603725
home
Home
Loading...
Technical Data
Cable length (m)
0.5
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
80
Application
Data
Number of Conductors
8
Core cross-section (mm²)
0.21
Network protocol
Ethernet
Cable quality
TPE
Cable color
Green
Approvals
UL
Connector A
Male, M12 × 1, Straight, A-coded
Number of Pins
8
Voltage (V)
60
Current (A)
2
Coupling nut/screw material A
Brass
Coupling nut/screw material B
Brass
Design
Extension Cable
Connector B
Male, M12 × 1, Straight, D-coded
Number of Pins
8
Key Features
Cable length (m)
0.5
Cable quality
TPE
Connector A
Male, M12 × 1, Straight, A-coded
Connector B
Male, M12 × 1, Straight, D-coded
In Stock
Price Group
D1
List Price
€48.90
