RKSW-D9-RKSW-451-0.3M-0.3M | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
PROFIBUS Cable
RKSW-D9-RKSW-451-0.3M-0.3M
Order ID no. 6604659
home
Home
Loading...
Technical Data
Cable length (m)
0.3
Ambient temperature min. (°C)
-25
Ambient temperature max. (°C)
80
Application
Data
Number of Conductors
2
Core cross-section (mm²)
0.34
Network protocol
PROFIBUS-DP
Cable quality
PUR
Cable color
Violet
Approvals
UL
Connector A
2 × female connectors, M12 × 1, Straight, B-coded
Number of Pins
5
Voltage (V)
250
Current (A)
4
Coupling nut/screw material A
Brass
Design
Y-splitter with cable
Connector B
Male, D-Sub, Angled
Number of Pins
9
Key Features
Application
Data
Connector A
2 × female connectors, M12 × 1, Straight, B-coded
Connector B
Male, D-Sub, Angled
In Stock
Price Group
K1
List Price
€110.55
